Frames for mounting LED panels on ceilings. Make it possible to use SLIMFLUX panels in ceilings where there is no possibility to install recessed panels; frames can hide the drivers. Epoxy painted extruded aluminium separated into 4 bars to be assemble while mounting. Easy and fast mounting directly on the surface. White color.Are mounted fixing directly the frame to the surface.

Frame with springs for recessed installation of LED panels in non-modular ceilings. Set of 4 extruded aluminium profiles to be easily assembled with corner spring-brackets. White color.

Standby emergency kitEmergency electronic unit for standby lighting (as indicated by the UNI EN 1838) suitable for current controlled power LED.
Can be used for maintained or emergency operation.
Can be used with max 2A - 90V.
Battery life: 3 hours (battery pack dimensions: 135 x 45 x 23 mm).
Battery inserted in a protective case in accordance with regulations.
Residual flux in emergency 7%.

Reserve lighting means lighting that allows you to continue normal activity without substantial change.
Fixtures indicated as compatible with the kit have passed the required tests for the reserve lighting category in compliance with EN 60598-2-22.

Junction box for connection to the mains, prepared for connection in cascade, equipped with safety suspension kit with steel cable for installations in seismic zones.

Junction box for connection to the power supply network, prepared for connection in cascade (cable length 27 cm).

Adjustable suspension cables

Metal springs kit for recessed installation - 4 pieces.

MULTICURRENT DIMMABLE DRIVER 50WDALI 2 - 1-10V - DALI Push
Suitable for use in a centralised power supply for emergency lighting.
Preset power supply for Slimflux CCT panels, 680mA OUT.
